Rsv4 1100

Tipologia

Sportiva

Cilindrata

1099.0 cc (67.06 cubic inches)

Tipo motore

V4, four-stroke

Dettagli motore

Longitudinal 65° V4

Potenza

217.0 CV (158.4 kW)) @ 13000 giri/min

Velocita massima

305.0 km/h (189.5 mph)

Regime massimo

12300

Rapporto di compressione

13.6:1

Alesaggio x corsa

81.0 x 52.3 mm (3.2 x 2.1 inches)

Valvole per cilindro

4

Sistema di alimentazione

Injection. Airbox with front dynamic air intakes. 4 Marelli 48-mm throttle bodies with 8 injectors and Ride-By-Wire engine management.

Controllo alimentazione

Double Overhead Cams/Twin Cam (DOHC)

Accensione

Magneti Marelli digital electronic ignition system integrated in engine control system, with one spark plug per cylinder and "stick-coil" type coils

Sistema di lubrificazione

Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)

Frizione

Multiplate wet clutch with mechanical slipper system.

Trasmissione finale

Gear lever with Aprilia Quick Shift electronic system (AQS)

Consumo carburante

6.90 litres/100 km (14.5 km/l or 34.09 mpg)

Emissioni serra

160.1 CO2 g/km. (CO2 - emissione di anidride carbonica)

Dettagli emissioni

Euro 5

Impianto di scarico

4 into 2 into 1 layout, single oxygen sensor, lateral single silencer with ECU-controlled bypass valve and integrated trivalent catalytic converter (Euro 3)

Inclinazione cannotto di sterzo

24.6°

Avancorsa

105 mm (4.1 inches)

Escursione anteriore

127 mm (5.0 inches)

Escursione posteriore

130 mm (5.1 inches)

Diametro

330 mm (13.0 inches)

Diametro

220 mm (8.7 inches)

Ruote

Aprilia in aluminium alloy wheels with 3 split spoke design

Peso a secco

179.0 kg (394.6 pounds)

Weight incl. oil, gas, etc

202.0 kg (445.3 pounds)

Rapporto potenza/peso

1.2123 CV/kg

Altezza sella

845 mm (33.3 inches) If adjustable, lowest setting.

Altezza totale

1090 mm (42.9 inches)

Lunghezza totale

2055 mm (80.9 inches)

Larghezza totale

735 mm (28.9 inches)

Altezza da terra

125 mm (4.9 inches)

Interasse

1436 mm (56.5 inches)

Capacita carburante

17.90 litres (4.73 US gallons)

Capacita carburante di riserva

4.00 litres (1.06 US gallons)

Colori disponibili

Sachsenring Black/Red, Silverstone Grey/Red

Avviamento

Elettrico

Strumentazione

TFT color instrumentation

Impianto elettrico

Flywheel mounted 420W alternator with rare earth magnets.

Fari

Triple LED headlight with two lights that illuminate the inside of the turn, increasing visibility when cornering.

Coppia

125.0 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 10500 giri/min

Sospensione anteriore

Sachs fork 43mm stanchions, adjustable compression and rebound

Sospensione posteriore

Sachs monoshock adjustable in: hydraulic compression and rebound damping and spring pre-load.

Tipologia telaio

Aluminium dual beam chassis with cast and pressed sheet elements. (Sachs steering damper on APRC version)

Pneumatico anteriore

120/70-ZR17

Pneumatico posteriore

200/55-ZR17

Freno anteriore

Double disc. ABS. Ø 330 mm floating double disc with aluminium flange Brembo STYLEMA® 4-piston mono-block radial calipers Radial pump and metal braid brake pipe

Freno posteriore

Single disc. ABS. Brembo Ø 32 mm 2 isolated piston caliper pump with integrated tank and metal braid pipp

Cambio

6 marce

Tipo trasmissione

Catena (trasmissione finale)

Sistema di raffreddamento

Liquido
