Accedi per recensireIf maximum power is required, there is no other way but the 450 SX-F. This model has proven itself in the main championships around the world over the years. Thanks to its compact SOHC (single overhead camshaft) engine that delivers explosive but controllable power, it is the weapon of choice for the US KTM Factory Team and Ryan Dungey winning the AMA Supercross championship 2015.
Informazioni generali
Categoria
Cross / motocross
Cilindrata
449.3 cc (27.42 cubic inches)
Alesaggio x corsa
95.0 x 63.4 mm (3.7 x 2.5 inches)
Controllo alimentazione
Monoalbero a camme in testa (SOHC)
Accensione
Contactless controlled fully electronic ignition with digital ignition adjustment
Sistema di lubrificazione
Pressure circulation lubrication with two Eaton pumps
Frizione
Wet, DDS multi-disc clutch, Brembo hydraulics
Trasmissione finale
5/8 x 1/4
Inclinazione cannotto di sterzo
26.5°
Escursione anteriore
300 mm (11.8 inches)
Escursione posteriore
300 mm (11.8 inches)
Diametro
260 mm (10.2 inches)
Diametro
220 mm (8.7 inches)
Peso a secco
100.4 kg (221.3 pounds)
Altezza sella
960 mm (37.8 inches) If adjustable, lowest setting.
Altezza da terra
370 mm (14.6 inches)
Interasse
1485 mm (58.5 inches)
Capacita carburante
7.00 litres (1.85 US gallons)
Colori disponibili
Orange/black
Avviamento
Elettrico
Impianto elettrico
Lightweight 495 g lithium-ion starter battery
Motore
Tipo motore
Monocilindrico, quattro tempi
Sospensioni
Sospensione anteriore
WP-USD, AER 48, Ø 48 mm
Sospensione posteriore
WP shock absorber with linkage
Telaio
Tipologia telaio
25CrMo4 steel central-tube frame
Freni
Freno anteriore
Single disc. Brake calipers on floating bearings
Freno posteriore
Single disc. Brake calipers on floating bearings
Trasmissione
Cambio
4 marce
Tipo trasmissione
Catena (trasmissione finale)
Raffreddamento
Sistema di raffreddamento
Liquido
